Automatic Glue Dispenser

Automatic Glue Dispenser Specification

Product Type
Adhesive Dispensing Robot

General Use
glue dispensing

Material
Stainless Steel, ABS Plastic

Type
Pneumatic

Capacity
10ml to 100ml per cycle (adjustable)

Weight (kg)
Approx. 7 kg

Computerized
Yes

Automatic
Yes

Control System
Semi Automatic

Function
Precise Glue Dispensing

Working Temperature
5C - 40C

Gas Bottle Volume
Up to 1 Liter

Voltage
220V / 50Hz

Dimension (L*W*H)
300mm x 230mm x 200mm

Feature
Adjustable Flow Rate, Digital Display, Foot Pedal Operation

Color
White/Grey

Power Consumption
20W

Operation Mode
Hands-Free Foot Switch and Manual Trigger

Dispensing Speed
0.01 - 99.99 seconds/cycle

Application Industries
Electronics, Automotive, Toys, Medical Devices, Craftwork

Noise Level
<50 dB

Display
LED Digital Panel

Operating Pressure
0.1 - 0.9 MPa

Accessories Included
Dispenser Controller, Air Hose, Glue Syringe, Foot Pedal

Timing Mode
Adjustable Timed and Manual Modes

Nozzle Size
Customizable (commonly 0.2mm - 1.5mm)

Dispensing Accuracy
0.5%

Glue Type Supported
Epoxy, Silicon, UV, AB, and other liquid adhesives

Automatic Glue Dispenser Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Week

Delivery Time
4 Days

Sample Policy
Contact us for information regarding our sample policy

Main Domestic Market
All India

About Automatic Glue Dispenser

Digital display dispensing time and space time very clearlystandard configuration. Vaccum structure prevent droolingwidely applicable pressure rangecan suit various viscosity liquidswill be very easy to debug, having debugging switchwith perfect liquid dropping signal terminal functions can be used with robot use

Precision at Its Core

Engineered with an advanced control system and precise pneumatic dispensing, this machine guarantees glue output accuracy within 0.5%. Its LED digital display allows operators to effortlessly set and monitor dispensing parameters, making it ideal for tasks demanding consistency and repeatability. From delicate electronics to robust automotive components, precise application is assured every time.

Flexible and Easy to Operate

Supporting adjustable timing (from 0.01 to 99.99 seconds per cycle) and customizable nozzle sizes, this dispenser is equipped to handle varying adhesive viscosities and project requirements. Switch between hands-free foot pedal activation and manual trigger operation as needed, maximizing productivity and user comfort in fast-paced environments.

Built for Diverse Industrial Needs

With compatibility for epoxy, silicon, UV, AB, and other liquid adhesives, the dispenser is an all-purpose solution for production lines and workshops. Accessories such as air hose, glue syringe, and controller are included for immediate setup. Its durable construction from stainless steel and ABS plastic ensures long-term reliability and easy cleaning.

FAQ's of Automatic Glue Dispenser:

Q: How do I operate the Automatic Glue Dispenser in hands-free mode?

A: The dispenser includes a foot pedal for hands-free operation. Simply connect all accessories as per the manual, set your desired dispensing parameters using the LED digital panel, and use the foot pedal to control glue flow cycles. This mode is particularly useful for repetitive assembly tasks.

Q: What glue types can I use with this dispenser?

A: This model supports a wide range of liquid adhesives, such as epoxy, silicon, UV, AB glue, and other compatible viscous liquids. Always confirm the adhesive's viscosity and compatibility with pneumatic dispensing before use.

Q: When should I adjust dispensing time and flow rate parameters?

A: Adjust these settings whenever you switch between adhesives of different viscosities or need to modify the amount of glue per cycle. Use the digital display to precisely set the timing (0.01-99.99 seconds) and control the flow for optimal results in various application scenarios.

Q: Where can the automatic glue dispenser be effectively applied?

A: This device is engineered for versatility across several industries, including electronics manufacturing, automotive components, toys, medical device production, and craftwork. Its precise control and flexible settings suit both detailed assembly and general production tasks.

Q: What are the main benefits of using this automatic glue dispenser?

A: Key advantages include maximized precision in glue application, reduced operator fatigue via foot pedal control, adjustable settings for various adhesives, low noise operation, and efficient, repeatable output which enhances production line consistency and quality.

Q: How do I maintain the dispenser for optimal performance?

A: Regularly clean the nozzle and syringe after each use to prevent clogs. Periodically check for air leaks in hoses and ensure the pneumatic system is free of contaminants. Follow the manufacturer's recommendations for routine maintenance to extend the machine's lifespan.
